PP20
£447.30
£372.75
In stock
SKU
FT-PP20
PRISMA PLASTIC PP20 DA ACTUATOR
PRISMA PLASTIC PP20 DA ACTUATOR
Features: 0-90ﾰ rotation angle to pilot ball, butterfly and plug valves. Double acting torques from 17 to 165.5 Nm at 6 bar. Single acting torques from 6.7 to 65.8 Nm end of spring. Polyamide body. ATEX II 2G Ex h IIC T6 Gb / II 2D Ex h IIIC T80ﾰC Db certification. SIL3 rated. Conforms to ISO 5211, DIN 3337 and VDI/VDE 3845. NAMUR pneumatic connection for solenoid valve installation.
BearingShopUK holds a large stock of Process Valves and Instrumentation equipment, including the PP20 Range of Pneumatic Actuator.
Please allow 3-4 days for delivery from our Fluid Power Branch.
Please view the below PDF for more information,
Features: 0-90ﾰ rotation angle to pilot ball, butterfly and plug valves. Double acting torques from 17 to 165.5 Nm at 6 bar. Single acting torques from 6.7 to 65.8 Nm end of spring. Polyamide body. ATEX II 2G Ex h IIC T6 Gb / II 2D Ex h IIIC T80ﾰC Db certification. SIL3 rated. Conforms to ISO 5211, DIN 3337 and VDI/VDE 3845. NAMUR pneumatic connection for solenoid valve installation.
BearingShopUK holds a large stock of Process Valves and Instrumentation equipment, including the PP20 Range of Pneumatic Actuator.
Please allow 3-4 days for delivery from our Fluid Power Branch.
Please view the below PDF for more information,
