LD202

LOGIDRAIN 202
The new series of LogiDrain level drains has been designed to solve the problem of condensation water drainage from production plants and compressed air distribution systems. The specific technology applied permits a controlled drainage of condensation water without any compressed air leaks. LogiDrain is equipped with an integrated storage tank with a level sensor, controlled by an intelligent electronic circuit based on 8-bit microprocessor logic. All drain functions are displayed on a control panel. A test push button is available on the control panel for manual drainage. LogiDrain starts working as soon as the sensor detects water at the maximum level and controls the solenoid valve opening to take the water level back down to a minimum value, leaving a small residual quantity to prevent the system from discharging compressed air. In case of trouble, the control circuit unlocks the drain pipes by carrying out a series of forced opening and closing cycles of the solenoid valve. Problems are reported outside by an alarm with potentialfree contact that can be used to draw the attention of maintenance staff in order to instruct the plant control logic. LogiDrain is produced in several models with different flow rates. All versions are suitable for working with any type of condensation water, even the most aggressive one or water containing a high percentage of oil. A built-in cup filter, easy to clean, prevents the solenoid valve from clogging. Zero loss drain system. Intelligent logic based on an 8-bit microprocessor recording events in integral flash memory. Revolving easy lock connection. Integrated filter to collect contaminated condensate. FKM (fluoroelastomer) diaphragm. Remote alarm connection. Hard-coated aluminium storage tank (200 series).
BearingShopUK holds a large stock of Compressed Air and Ring Main equipment, including the LD202 Range of Condensate.

Please allow 3-4 days for delivery from our Fluid Power Branch.

Please view the below PDF for more information,
