FULL-KIT

FULL PELLET LAUNCHER KIT 31PCS 6-50MM
The pellet launcher uses compressed air to fire a foam pellet through hose, pipe or tube clearing soft deposits and loose debris as it travels through. The pellet launcher is designed to operate at 80-110 psi and should be connected, by a 3/8"(10mm)ID air line, to an air source NOT exceeding 150 psi. Pellets used in the system will travel through 90 degree angles, tee joints, coils, U tubes, bore and straight-through valves. The specially designed and extremely robust pellet launcher controls the air flow. It attaches to the 32 mm and 50 mm heads through a patented interlocking system. The nozzles are inserted into the head. These are designed to reduce the pellet in size for insertion into the pipe. All nozzles fit into either the 32mm or 50mm heads. All kits come in a case with instruction manuals and a pellet usage chart for identifying the correct pellets to use with your application.This Kit consist of the following: AM-1ﾙ Hand Piece, 32mm and 50mm heads, White Hose Nozzles 6, 8, 10, 13, 16, 19, 25, 32, 38 and 50mm, Green Tube & JIC Nozzles 5, 6, 8, 10, 13, 16, 19, 22, 25, 32, 38 and 50mm, Blue BSP Nozzles 6, 10, 13, 16, 19, 25 and 32mm
BearingShopUK holds a large stock of Hydraulic equipment, including the FULL-KIT Range of Pellet Launcher Kit.

Please allow 3-4 days for delivery from our Fluid Power Branch.

Please view the below PDF for more information,
TS60439
