CZT-81 506 025

NO GATE (THRESHOLD) DARK GREY
2.7mm orifice, 170 L/min. Greater than 107 operations. Function: OR Element The output signal ﾂ"Sﾂ" is present when a signal at ﾂ"aﾂ" OR ﾂ"bﾂ" is present. S = a OR b. AND Element The output signal ﾂ"Sﾂ" is present only when signals ﾂ"aﾂ" AND ﾂ"bﾂ" are present simultaneously. S = a AND b. YES Element The output signal ﾂ"Sﾂ" is only present when the pilot is present. S = a YES b. NOT Element The output signal ﾂ"Sﾂ" is present only if the input signal ﾂ"aﾂ" is NOT present. The output signal is therefore the inverse of the pilot signal. S = NOT a. If the supply port is connected to a 2nd input ﾂ"bﾂ" the function obtained is called Inhibition. S=NOT a AND b. Note: Switching time = <4ms exception OR and AND.
BearingShopUK holds a large stock of Pneumatics and Vacuum equipment, including the CZT-81 506 025 Range of Element.

Please allow 3-4 days for delivery from our Fluid Power Branch.

Please view the below PDF for more information,
TS1512
